Figure 2.3 Monitoring Unit Front Panel
Number Description
1 Status / alarm indicator
2 Digital Output (DO) port
3 Digital Input (DI) port
4 Smoke detector port
5 Sensor group 1 x 2 ports and sensor group 2 x 2 ports
6 COM / Serial ports
7 4 x Expansion slot
Table 2.14 Monitoring Unit Front Panel Description
Figure 2.4 Monitoring Unit Rear Panel
