Figure 7.21 CR019 Temperature Control Settings
Setting Configuration
Temperature Control Sensor Remote (predefined value)
Temperature Setpoint 68 °F (20°C)
Table 7.10 CR019 Temperature Control Configurations
NOTE: The temperature setpoint can also be modified via the main HMI display located on the PMC. For more
information, please refer to Thermal on page73 .
Teamwork Mode
NOTE: The Teamwork function is available only for the redundant 20kWcooling system.
Teamwork Mode should be set to Mode 3 for optimized aisle teamwork. In this mode, the fan speed operation for each unit is
identical; however, the cooling capacity operates independently for each unit.
Teamwork mode 3 takes advantage of variable-speed fan options and variable capacity component options to maintain
rooms with an unbalanced load and to prevent units in a group from operating in opposing modes. Both units operate in the
same mode based on the average or worst case (maximum) readings from the unit sensors.
7 Network Settings Proprietary and Confidential ©2024 Vertiv Group Corp. 69
Vertiv™ SmartRow™ 2 Infrastructure Solution User Guide
