Vicon VDR-704C - JPEG Frame Rate Setup; Dual Codec Setup; System Setup Menu Configuration

Main Menu Configuration
34
3.6.3. JPEG Frame Rate Setup
This is to set up JPEG frame rate to transmit to network. H.264 streaming is used for recording and JPEG streaming
is for network application.
Max. Value of JPEG Frame Rate
The maximum JPEG frame rate transferred via network is to take the lowest value either from JPEG
frame rate setting value, or from H.264 Recording frame rate.
3.6.4. Dual Codec Setup
Figure 3.37. Dual Codec Setup
This is to set up resolution, video quality and frame rate etc. of H.264 for network transfer streaming.
3.7. System Setup Menu Configuration
Figure 3.38. System Setup Screen
