100 Commissioning WAGO-I/O-SYSTEM 750
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.1.4 “PLC Runtime Information” Page
All information about the enabled runtime system and PLC program created in the
programming software is provided on the “PLC Runtime Information” page.
7.6.1.4.1 “PLC Runtime” Group
Table 42: WBM “PLC Runtime Information” Page – “PLC Runtime” Group
Parameters
Explanation
Version
The version of the currently activated runtime
system is shown here.
If the runtime system is disabled, “None” is
displayed and the subsequent fields of this group are
disabled.
Web Server Version
This shows the version number of the web server.
This field is only visible when CODESYS 2 is
enabled as the runtime system.
State
The PLC operating state is shown. This field is only
visible when CODESYS 2 is enabled as the runtime
system.
STOP
PLC program is not executed.
RUN
PLC program is executed.
Number of Tasks
The number of tasks in the PLC program is shown.
This field is only visible when CODESYS 2 is
enabled as the runtime system.
7.6.1.4.2 “Project Details” Group
This group is only visible if CODESYS 2 is enabled as the runtime system.
Table 43: WBM “PLC Runtime Information” Page – “Project Details” Group
Parameters
Explanation
Date
Display of project information that the programmer
entered in the PLC program (in programming
software under Project > Project Information...).
The information only appears when a PLC program
is run.
Descriptive texts up to 1024 characters long are
given under “Description.”
Title
Version
Author
Description
