166 Commissioning WAGO-I/O-SYSTEM 750
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.4.4.7 “TCP/IP” > “Default Gateway” Submenu
This submenu contains other submenus with settings for the default gateway.
Table 130: “Networking” > “TCP/IP” > “Default Gateway” Submenu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. Default Gateway 1
Opens a submenu with settings for default gateway 1
In addition to the menu item, the current status of the
gateway is displayed.
2. Default Gateway 2
Opens a submenu with settings for default gateway 2
In addition to the menu item, the current status of the
gateway is displayed.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
7.6.4.4.8 “Default Gateway” > “Default Gateway n” Submenu
This submenu contains the settings for the selected gateway.
Table 131: “Networking” > “TCP/IP” > “Default Gateway” > “Default Gateway n” Submenu
Menu Item
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. State
Set here whether the selected default gateway is to
be used.
0. Back to …
Back to the higher-level menu
1. Disabled
The default gateway is not used.
2. Enabled
The default gateway is used.
2. Gateway IP Address
Enter the address of the default gateway.
3. Gateway Metric
Set here a number as the metric.
The default value for the metric is 20, the lowest
value is 0, the highest value is 4.294.967.295.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
