144 Commissioning WAGO-I/O-SYSTEM 750
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
</dg_
7.6.1.34 “Configuration of SNMP v3 Users” Page
The general settings for SNMP v3 are shown on the “Configuration of SNMP v3
Users” page.
7.6.1.34.1 “Actually Configured v3 Users” Group(s)
Table 96: WBM “Configuration of SNMP v3” Page – “Actually Configured v3 Users” Group
The number of configured v3 users is displayed.
7.6.1.34.2 “v3 User n” Group(s)
A group with the following information is displayed for each user:
Table 97: WBM “Configuration of SNMP v3 Users” Page – “v3 User n” Group(s)
Security Authentication
Name
The user name is displayed.
Authentication Type
The authentication type for the SNMP v3 packets is
displayed here.
Possible values:
- Use no authentication (“None”)
- Message Digest 5 (“MD5”)
- Secure Hash Algorithm (“SHA”)
Authentication Key (min.
eight char.)
The authentication key is displayed.
Privacy
The encryption algorithm for the SNMP message is
displayed here.
Possible values:
- No encryption (“None”)
- Data Encryption Standard (“DES”)
- Advanced Encryption Standard (“AES”)
Privacy Key (min. eight
char.)
The key for encryption of the SNMP message is
displayed here. If nothing is displayed here, the
“authentication key” is automatically used.
Notification Receiver IP
The IP address of a trap receiver for v3 traps is
displayed here. If no v3 traps are to be sent for this
user, this field remains blank.
Click [Delete] to delete the user. The changes only take effect after restarting the
controller. For this purpose, use the WBM reboot function. Do not shut down the
controller too early!
