108 Commissioning WAGO-I/O-SYSTEM 750
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.1.9 “Ethernet Configuration” Page
The settings for Ethernet TCP/IP are located on the “Ethernet Configuration”
page.
7.6.1.9.1 “Switch Configuration” Group
Table 52: WBM “Ethernet Configuration” Page – “Switch Configuration” Group
Interfaces
Enable or disable the switch.
Switched
Both interfaces are operated with one
IP address.
Separated
Each interface is operated with its own
IP address.
Port Mirror
Enable or disable the mirroring of the data traffic
between the ports.
Both Ethernet ports operating normally.
X1
The entire data traffic between X1 and
the PFC system is mirrored at port X2.
X2
The entire data traffic between X2 and
the PFC system is mirrored at port X1.
Fast Aging enabled
Set here the aging time of unused entries in the list of
MAC addresses with a port assignment to external
Disabled
An unused address entry becomes
obsolete after 200 seconds.
Enabled
An unused address entry becomes
obsolete after 800 microseconds.
Broadcast Protection
Set here the broadcast limit for protection against
overloads.
No limitation of broadcast packets.
1 % ... 5 %
Limitation of incoming broadcast
packets to the selected percentage of
the total possible data throughput
Rate Limit
Set here the basic limitation of the incoming data
traffic.
Disabled
No limitation of the incoming data
traffic
Limitation of the incoming data traffic
to the entered value
Click [Submit] to apply the change. The change is effective immediately.
7.6.1.9.2 “Interface Xn” Groups
One group (“Interface X1” / “Interface X2”) is displayed for each connection.
