WAGO-I/O-SYSTEM 750 Commissioning 143
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.1.33.3 “Trap Receiver n” Group(s)
A dedicated group with the following information is displayed for each trap
receiver:
Table 94: WBM “Configuration of SNMP v1/v2c Parameters” Page – “Trap Receiver n” Group(s)
IP Address
The IP address for the trap receiver (management
station) is displayed here.
Community Name
This displays the community name for the trap
receiver configuration. The community name can be
evaluated by the trap receiver.
Version
This displays the SNMP version, via which the traps
are sent: v1 or v2c (traps higher than v3 are
displayed in a separate form).
Click [Delete] to delete the trap receiver. The changes only take effect after
restarting the controller. For this purpose, use the WBM reboot function. Do not
shut down the controller too early!
7.6.1.33.4 “Add New Trap Receiver” Group
You can enter 10 trap receivers.
Table 95: WBM “Configuration of SNMP v1/v2c Parameters” Page – “Add New Trap Receiver”
Group
IP Address
Specify the IP address for the new trap receiver
(management station) here.
Community Name
Specify here the community name for the new trap
receiver configuration. The community name can be
evaluated by the trap receiver.
The community name can be up to 32 characters
long and must not include spaces.
Version
Specify the SNMP version that will send the traps:
v1 or v2c (traps higher than v3 are configured in a
Click [Add] to add a new trap receiver. The changes only take effect after
restarting the controller. For this purpose, use the WBM reboot function. Do not
shut down the controller too early!
