WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 Commissioning 165
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.4.4.5 “TCP/IP” > “IP Address” Submenu
This submenu contains other submenus with settings for the ETHERNET
interfaces.
The submenu only appears if the controller is operated in “Separated” mode.
If the controller is operated in “Switched” mode, then the “IP Address” > “X1”
submenu is displayed directly.
Table 128: “Networking” > “IP Address” Submenu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. X1
Opens a submenu with settings for the X1 interface
2. X2
Opens a submenu with settings for the X2 interface
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
7.6.4.4.6 “IP Address” > “Xn“ Submenu
This submenu contains the settings for the selected interface.
Table 129: “Networking” > “TCP/IP” > “IP Address” Submenu > “Xn”
Menu Item
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. Type of IP Address
Configuration
Select a static or dynamic IP address.
0. Back to …
Back to the higher-level menu
1. Static IP
Static IP addressing
When selecting static addressing, the
IP address and subnet mask are then
retrieved.
2. DHCP
Dynamic IP addressing
3. BootP
Dynamic IP addressing
2. IP Address
Enter here a static IP address.
3. Subnet Mask
Enter the subnet mask.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
