114 Commissioning WAGO-I/O-SYSTEM 750
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.1.12 “Configuration of User Filter” Page
7.6.1.12.1 “User Filter” Group
Table 59: WBM “Configuration of User Filter” Page – “User Filter” Group
Parameters
Explanation
Count
The number of configured user filters is displayed.
7.6.1.12.2 “User Filter n” Group
Table 60: WBM “Configuration of User Filter” Page – “User Filter n” Group
Parameters
Explanation
Source IP address
The source IP address for the respective filter entry
is displayed.
Source netmask
This displays the source network for the
corresponding filter entry.
Source port
The source port number for the respective filter entry
is displayed.
Destination IP address
The destination IP address for the respective filter
entry is displayed.
Destination subnet mask
The destination network mask for the respective
filter entry is displayed.
Destination port
The designation port number for the respective filter
entry is displayed.
Protocol
The permitted protocols for the respective filter is
displayed.
Input interface
The permitted interfaces for the respective filter are
displayed.
Policy
Hier wird angezeigt, ob der Netzwerkteilnehmer
durch den Filter zugelassen oder ausgeschlossen ist.
Click the appropriate [Delete] button to remove a configured filter. The change is
effective immediately.
