WAGO-I/O-SYSTEM 750 Commissioning 105
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
</dg_
7.6.1.8 “TCP/IP Configuration” Page
The TCP/IP settings for the ETHERNET interfaces are shown on the “TCP/IP
configuration” page.
7.6.1.8.1 “IP Configuration (Xn)” Group(s)
If the switch is enabled, one group (“IP Configuration”) is shown for both
connections.
If the switch is disabled, a separate group (“IP Configuration X1” / “IP
Configuration X2”) is shown for each connection.
Table 49: WBM “TCP/IP Configuration” Page “IP Configuration (Xn)” Group(s)
Parameters
Explanation
Configuration Type
Select a static or dynamic IP address.
Static IP
Static IP addressing
DHCP
Dynamic IP addressing
BootP
Dynamic IP addressing
IP Address
Enter here a static IP address. This is enabled if
“Static IP” is enabled in the Configuration Type
field.
Subnet Mask
Enter the subnet mask. This is enabled if “Static IP
is enabled in the Configuration Type field.
Click [Submit] to apply changes. The changes are effective immediately.
