WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 Removal 395
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
14 Removal
Risk of injury due to sharp-edged blade contacts!
The blade contacts are sharp-edged. Handle the I/O module carefully to prevent
injury.
14.1 Removing Devices
Perform work on devices only if they are de-energized!
Working on energized devices can damage them. Therefore, turn off the power
supply before working on the devices.
14.1.1 Removing the Controller
1. Use a screwdriver blade to turn the locking disc until the nose of the locking
disc no longer engages behind the carrier rail.
2. Remove the controller from the assembly by pulling the release tab.
Electrical connections for data or power contacts to adjacent I/O modules are
disconnected when removing the controller.
Figure 178: Release Tab of Controller
Do not take the controller enclosure apart!
The enclosure sections are firmly joined. The feed-in section with the CAGE
CLAMP
®
connections cannot be separated from the other enclosure section.
