WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 Commissioning 175
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.4.5.4 “MAC Address Filter” > “MAC address filter whitelist” Submenu
This submenu displays all available filter entries.
Table 141: “Firewall” > “MAC Address Filter” > “MAC address filter whitelist” Submenu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. Add new
Opens a submenu to add a new filter entry
You can enter 10 filters.
2. Previous page
Displays the previous page of the list (if more than
one page is filled)
3. Next Page
Displays the next page of the list (if more than one
page is filled)
(n + 3.) No (n):
Opens a submenu to edit an existing filter entry
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
7.6.4.5.5 “MAC address filter whitelist” > “Add new / No (n)” Submenu
In this submenu, you can create, change or delete filter entries.
Table 142: “Firewall” > “MAC Address Filter” > “MAC address filter whitelist” > “Add new / No
(n)” Submenu
Menu Item
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. MAC address
Enter the MAC address.
2. MAC mask
Enter the MAC mask.
3. Filter state
Enable or disable the filter.
0. Back to …
Back to the higher-level menu
1. on
The filter is enabled.
2. off
The filter is disabled.
4. accept
To apply the changes for the selected filter entry,
choose this menu item.
5. delete
To delete the selected filter entry, choose this menu
item.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
