WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 MODBUS – CODESYS 2 265
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
9.3.2 MODBUS TCP Settings
The “MODBUS TCP Settings” contains the following configuration parameters
for the “MODBUS TCP” mode:
Table 194: MODBUS TCP Settings
Parameters
Explanation
TCP mode
Enable for the MODBUS TCP mode
Off
Operation not permitted
Active
*
Operation possible
TCP port
Port number for the TCP link
1
Minimum port number
502
*
MODBUS default port
65535
Maximum port number
TCP Timeout
Time-out for a TCP link
1
100 ms (1 × 100 ms)
600
*
60 seconds (600 × 100ms)
65535
1 h 49 min 13 s 500 ms (65535 × 100 ms)
*
Default setting
9.3.3 MODBUS UDP Settings
The “MODBUS UDP Settings” group contains the following configuration
parameters for the “MODBUS UDP” mode:
Table 195: MODBUS UDP Settings
Parameters
Explanation
UDP mode
Enable for the MODBUS UDP mode
Off
Operation not permitted
Active
*
Operation possible
UDP port
Port number for the UDP link
1
Minimum port number
502
*
MODBUS default port
65535
Maximum port number
*
Default setting
9.3.4 MODBUS RTU Settings
The “MODBUS RTU Settings” group contains the following configuration
parameters for the “MODBUS RTU” mode:
