WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 Commissioning 135
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
7.6.1.26 “Configuration of PLC Runtime Services” Page
The settings for various services of the enabled runtime system are shown on the
“Configuration of PLC Runtime Services” page.
7.6.1.26.1 “General Configuration” Group
Table 83: WBM “Configuration of PLC Runtime Services” Page – “General Configuration” Group
Parameters
Explanation
Port Authentication
Password
Enter the new password for port authentication.
Confirm Password
Enter the new password again for confirmation.
Click [Submit] to apply change. The change is effective immediately.
7.6.1.26.2 “CODESYS 2” Group
Table 84: WBM “Configuration of CODESYS Services” Page – “CODESYS 2 Webserver” Group
Parameters
Explanation
CODESYS 2 State
This displays the status (enabled/disabled) of the
CODESYS 2 runtime system.
Webserver enabled
Enable or disable the CODESYS 2 Webserver for
the CODESYS web visualization.
Communication enabled
Enable or disable the communication between the
CODESYS 2 runtime system and the CODESYS 2
programming system.
Communication Port
Number
Enter here the port number for communication with
the CODESYS 2 programming system. Default
value is 2455.
Port authentication enabled
Define here whether port authentication is enabled.
If this is enabled, the password specified under
“General Configuration” must be entered when
logging in via CODESYS 2 IDE.
Click [Submit] to apply change. The change is effective immediately.
