WAGO I/O-SYSTEM 750 User Manual

WAGO-I/O-SYSTEM 750 Run-time System CODESYS 2.3 241
750-8208 PFC200 CS 2ETH RS CAN DPM
Manual
Version 1.1.0, valid from FW Version 02.06.20(09)
Table 185: Access to the Process Images of the Input and Output Data – MODBUS
Memory area
Description
Access via
PLC
Logical Address Space
MODBUS input
process image
MODBUS input variables,
addressed by word via MODBUS
Read
Word
%IW1000 to %IW1999
Byte
%IB2000 to %IB3999
MODBUS input variables,
addressed by bit via MODBUS
Read
Bit
%IX1000.0 …%IX1000.15
to %IX1384.0 …
%IX1384.15
MODBUS output
process image
MODBUS output variables,
addressed by word via MODBUS
Read/
Write
Word
%QW1000 to %QW1999
Byte
%QB2000 to %QB3999
MODBUS output variables,
addressed by bit via MODBUS
Read/
Write
Bit
%QX1000.0 …
%QX1000.15 to
%QX1384.0 …
%QX1384.15
Table 186: Access to the Process Images of the Input and Output Data – CANopen
Memory area
Description
Access via
PLC
Logical Address Space
CANopen input
process image
CANopen master or CANopen
slave input variables
Read
Word
%IW3000 to %IW4999
Byte
%IB6000 to %IB9999
CANopen output
process image
CANopen master or CANopen
slave output variables
Read/
Write
Word
%QW3000 to %QW4999
Byte
%QB6000 to %QB9999
Table 187: Access to the Process Images of the Input and Output Data – PROFIBUS
Memory area
Description
Access via
PLC
Logical Address Space
PROFIBUS input
process image
PROFIBUS input variables
Read
Word
%IW5000 to %IW7499
Byte
%IB10000 to %IB14999
PROFIBUS
output process
PROFIBUS output variables
Read/
Write
Word
%QW5000 to %QW7499
Byte
%QB10000 to %QB14999
