Watlow F4T • 171 • Chapter 5 Function Reference
Direction Label Type Function
Transmitters
SP1 Analog Set point driven by the profile for use by a control loop
SP2 Analog Set point driven by the profile for use by a control loop
SP3 Analog Set point driven by the profile for use by a control loop
SP4 Analog Set point driven by the profile for use by a control loop
EVT1 Digital
Event Output 1 set by the profile to drive an output or
other feature
EVT2 Digital
Event Output 2 set by the profile to drive an output or
other feature
EVT3 Digital
Event Output 3 set by the profile to drive an output or
other feature
EVT4 Digital
Event Output 4 set by the profile to drive an output or
other feature
EVT5 Digital
Event Output 5 set by the profile to drive an output or
other feature
EVT6 Digital
Event Output 6 set by the profile to drive an output or
other feature
EVT7 Digital
Event Output 7 set by the profile to drive an output or
other feature
EVT8 Digital
Event Output 8 set by the profile to drive an output or
other feature
PRF Analog The number of the profile that is running
RUN Digital On indicates the profile is running
PAUS Digital On indicates the profile is paused
Power Out Minutes
Set the minutes portion of the power failure recovery time limit for profiles. If power is lost
while a profile is running, and power is restored within the time limit, the profile resumes
where it left off.
Range: 0 to 59
Power Out Hours
Set the hours portion of the power failure recovery time limit for profiles. If power is lost
while a profile is running, and power is restored within the time limit, the profile resumes
where it left off.
Range: 0 to 99
Minutes
Set the minutes portion of the time of day for the calendar start feature. This feature starts
the specified profile at the time and day specified with the Minutes, Hours and Day of Week
parameters.
Range: 0 to 59
