Watlow F4T • 181 • Chapter 5 Function Reference

Add

This function sums up to four inputs. Only inputs connected to a source are used in the calcu-

lation. A filter and offset may be applied to the calculated value. If any input is an absolute

temperature, the output is also an absolute temperature; otherwise the output’s units are

those of the signal connected to the top input.

Signals

Direction

Label Type Function

Receivers

- - - - Analog Value to be summed

Transmitter - - - - Analog The filtered sum of the inputs plus the offset

Function

To sum up to four inputs, set Function to Add.

Offset

Adjustment added to the result of the calculation.

Range: -99,999.000 to 99,999.000

Filter

Set the amount of filtering to apply. Filtering smooths signal fluctuations. Increase the time to

increase filtering. Excessive filtering slows the function’s response.

Range: 0.0 to 60.0 seconds

Multiply

This function multiplies up to four inputs. Only inputs connected to a source are used in the

calculation. A filter and offset may be applied to the calculated value. If any input is an ab-

solute temperature, the output is also an absolute temperature; otherwise the output’s units

are those of the signal connected to the top input.

Signals

Direction

Label Type Function

Receivers

- - - - Analog Value to be multiplied

Transmitter - - - - Analog The filtered product of the inputs plus the offset

Function

To compute the product of up to four inputs, set Function to Multiply.
