Watlow F4T • 309 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Rediscover Log Points
"No (59)
Yes (106)"
No (59)
"unsigned 16-bit
Access = RW"
42398
F4 Modbus Registers Migrated to F4T (Map 2)
Parameter Name Range Default
Data Type
and Access
(Read/Write)
Modbus
®
Registers
Model - - - - 4F 16-bit Unsigned R 0
Software ID 0 to 99 N/A 16-bit Unsigned R 3
Software Major Revision 0.00 to 9.99 N/A 16-bit Unsigned R 4
Save Changes to EE Save (0)
16-bit Unsigned
W
25
Process Value 1 - - - - N/A
16-bit Signed
R
100
Process Value 2 - - - - N/A
16-bit Signed
R
104
Closed Loop Set Point 1
Range Low 1 toRange
High 1
Depends on sensor
type
16-bit Signed RW 300
Idle Set Point 1 75 16-bit Signed RW 308
Closed Loop Set Point 2
Range Low 2 toRange
High 2
Depends on sensor
type
16-bit Signed RW 319
Idle Set Point 2 - - - - 75 16-bit Signed RW 327
Ramp Rate 1 to 999 N/A
16-bit Unsigned
RW
1101
Profile Action Resume 1 Resume (1)
16-bit Unsigned
W
1209
Profile Action Hold Hold (1)
16-bit Unsigned
W
1210
Terminate Profile Terminate (1)
16-bit Unsigned
W
1217
Profile Start File #
16-bit Unsigned
W
4000
Profile Start Step #
16-bit Unsigned
W
4001
Profile Action Start
Create (1)
Insert Step (2)
Delete Current profile (3)
Delete Step (4)
Start Profile (5)
Delete all Profiles (256)
16-bit Unsigned
W
4002
Profile Event Output 1
Off (0)
On (1)
Off
16-bit Unsigned
RW
2000 and 4030
Profile Event Output 2
Off (0)
On (1)
Off
16-bit Unsigned
RW
2010 and 4031
Profile Event Output 3
Off (0)
On (1)
Off
16-bit Unsigned
RW
2020 and 4032
Profile Event Output 4
Off (0)
On (1)
Off
16-bit Unsigned
RW
2030 and 4033
Profile Event Output 5
Off (0)
On (1)
Off
16-bit Unsigned
RW
2040 and 4034
Profile Event Output 6
Off (0)
On (1)
Off
16-bit Unsigned
RW
2050 and 4035
Profile Event Output 7
Off (0)
On (1)
Off
16-bit Unsigned
RW
2060 and 4036
Profile Event Output 8
Off (0)
On (1)
Off
16-bit Unsigned
RW
2070 and 4037
