Watlow F4T • 202 • Chapter 5 Function Reference
Signals
Direction Label Type Function
Receiver RUN Digital
Run signal for the timer. The timer runs when this input is
active and holds when this input is inactive.
Transmitter - - - - Digital Active whenever the time is greater than zero
Note:
The elapsed time is not retained through a power loss; it is set to zero upon power up.
Function
To trigger the output by setting the time, to have the timer count down while the input is ac-
tive, and have the output active until the time runs out, set Function to One Shot.
Time
Set the amount of time to count down. While the input is active this parameter counts down
until it reaches zero. The output is active whenever this parameter is greater than zero.
Range: 0 to 99,999.000
Run Active Level
Set in which state at RUN the timer counts down.
Options:
• High: on
• Low: off
Note:
The time is not retained through a power loss; it is set to zero upon power up.
Transmitter Active Level
Set the state of the output that indicates the timer is running or holding with a Time setting
greater than zero.
Options:
• High: On
• Low: Off
Elapsed Time
Indicates how long the timer has been running not including holding time. The value holds
whenever the input is inactive. The elapsed time resets to zero once the Time parameter has
counted down to zero.
Range: 0 to 99,999.000

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
