Watlow F4T • 285 • Chapter 6 Appendix
Parameter Class
and Name
Range Default
Data Type and
Attributes
Modbus Registers
Filtered Process Value
-99,999.000 to
99,999.000°F or
units, -55,572.778 to
55,537.222°C
"IEEE Float
Access=R"
"Temperature In 1:
Module 1, 32152
Temperature In 1:
Module 2, 32222
Temperature In 1:
Module 3, 32292
Temperature In 1:
Module 4, 32362
Temperature In 1:
Module 5, 32432
Temperature In 1:
Module 6, 32502"
Sensor Type
"Off (62)
Thermocouple (95)
RTD 100 Ohm (113)
RTD 1000 Ohm (114)"
Thermocouple (95)
"unsigned 16-bit
Access = RW"
"Temperature In 1:
Module 1, 32154
Temperature In 1:
Module 2, 32224
Temperature In 1:
Module 3, 32294
Temperature In 1:
Module 4, 32364
Temperature In 1:
Module 5, 32434
Temperature In 1:
Module 6, 32504"
TC Linearization
"B (11)
C (15)
D (23)
E (26)
F (30)
J (46)
K (48)
N (58)
R (80)
S (84)
T (93)"
J (46)
"unsigned 16-bit
Access = RW"
"Temperature In 1:
Module 1, 32156
Temperature In 1:
Module 2, 32226
Temperature In 1:
Module 3, 32296
Temperature In 1:
Module 4, 32366
Temperature In 1:
Module 5, 32436
Temperature In 1:
Module 6, 32506"
RTD Leads 2 (1) 2 (1)
"unsigned 16-bit
Access = RW"
"Temperature In 1:
Module 1, 32158
Temperature In 1:
Module 2, 32228
Temperature In 1:
Module 3, 32298
Temperature In 1:
Module 4, 32368
Temperature In 1:
Module 5, 32438
Temperature In 1:
Module 6, 32508"
Display Precision
"Whole (105)
Tenths (94)
Hundredths (40)
Thousandths (96)"
Whole (105)
"unsigned 16-bit
Access = RW"
"Temperature In 1:
Module 1, 32172
Temperature In 1:
Module 2, 32242
Temperature In 1:
Module 3, 32312
Temperature In 1:
Module 4, 32382
Temperature In 1:
Module 5, 32452
Temperature In 1:
Module 6, 32522"

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
