Watlow F4T User Manual

Symbol Explanation
Unit has been reviewed and approved by CSA International for use
as Temperature Indicating-Regulating Equipment per CSA C22.2 No.
24. See: www.csa-international.org
This F4T User’s Guide is copyrighted by Watlow Electric Manufacturing Company, © April 2016
with all rights reserved.
• © 2010-2012, QNX Software Systems Limited. All rights reserved.
• © 2008 -2014, Crank Software Inc. All rights reserved.
• Watlow
®
, Composer
®
and TRU-TUNE
®
are registered trademarks of Watlow Electric
Manufacturing Company.
• UL
®
is a registered trademark of Underwriter's Laboratories Incorporated.
• Modbus
®
is a registered trademark of Schneider Automation Incorporated.
• Vaisala
®
is a registered trademark of Vaisala OY Corporation.
• Microsoft
®
and Windows
®
are registered trademarks of the Microsoft Corporation.
Quencharc
®
is a registered trademark of ITW Paktron.
10-31815 Rev.

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
