上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
8 / 131
• Workpiece coordinates
• Machine coordinates
Compared with sheet cutting configuration, W-axis is added in tube cutting
configuration. This part takes sheet cutting configuration as an example:
To switch between workpiece coordinates and machine coordinates, do one of the
following:
• Click .
• Double click WorkCoor/MachCoor.
After returning to the machine origin, sign appears before each axis.
1.5.2 Feed Override Control Bar
It is used to control current feed speed by adjusting current feed override.
It is shown as follows:
The relationship among current feed speed, current feed override and set feed
speed is as follows:
Current feed speed = Current feed override * Set feed speed
To adjust feed override, do one of the following:
• Drag the slider.
• Click on the target position on the slider repeatedly.
• Click the slider and press ↑/↓ or PgUp/PgDown on the keyboard.
