上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
10 / 131
– Step mode
Click an axis direction button. The machine tool moves the customized
step size.
The default customized step size is 5mm. To customize the step size,
double click the feed mode button. The value should not be too large to
avoid damage due to misoperation.
Note: Please do not click an axis direction button too frequently because the system needs a certain time
to execute the command.
1.5.4 Common Operation Buttons
It is used to execute the following common operations:
• : All to origin
Used to return all axes to the machine origin.
• : Set workpiece origin
Used to set the workpiece origin.
• : Workpiece origin
Used to control the cutting head to return to the workpiece origin.
• : Calibrate
Used to set a follow-up height.
1.5.5 Machining Control Area
It includes the following:
• : Start
Used to start machining from the beginning.
• : Stop
Used to stop machining.
