Maintenance2303−1/A1
Winterthur Gas & Diesel Ltd.
4/ 6
I - I
II - II
FUEL SIDE
II
1
2
3
4
5
6
II
II
WCH03495
7
6
9
1, 2
3, 4
10
8
Fig. 6: Gland Box − General Views
1 Locking Plate 6 Bolt
2 Screw 7 Spring dowel pin
3 Locking Plate 8 2−part housing
4 Screw 9 Screw
5 Support 10 O-Rings
2016
Removal, Disassemble, Measure Worn Parts, Assemble, Installation
