Maintenance
3130−1/A1
Winterthur Gas & Diesel Ltd.
3/ 3
1
5
000.940/93
WCH02925
FREE END
OIL
SUPPLY
Note: Some parts can look different.
I - I
2
4
2
6
3
Fig. 2: Vibration Damper (section view)
1 Damper casing 4 Oil supply pipe
2 Vibration damper 5 Coupling bolt
3 Cover 6 Vent nozzle
Inspection (GEISLINGER Vibration Damper)
2016
