Maintenance
9403−5/A1
Winterthur Gas & Diesel Ltd.
37/45
94663A−IL
94663B−IL
1
1
Support LEFT
including: 1 Lug
1 Safety chain
8 Screws M16x40
X = 600 mm
Support RIGHT
including: 1 Lug
1 Safety chain
8 Screws M16x40
X = 600 mm
X
94663B−IL
X
94663A−IL
94663D
94663C−IL (DP)
DP
94663C−IL
94663D−IL
94663E−IL
94663F−IL
94664−IL
2
2
2
2
2
Lugs (only for SAC261, SAC265)
X = 155 mm
Safety chains
X = 1654 mm (SAC265)
(WLL 1000 kg)
Safety chains
X = 1222 mm (SAC261)
(WLL 1000 kg)
Safety chains
X = 1998 mm (SAC A44-SD)
(WLL 1000 kg)
Plates
including 4 hex. Head screws M20x50
X = 672.5 mm
X
016.822/08
X
X
94663C−IL
94663D−IL
94663E−IL
94663F−IL
WCH03304
94664−IL
94667 1
Tools for removal
and installation of water
separator (TC at DE)
Lifting plate
for removal and installation of water
separator
including:
4 screws M12x25
X = 305 mm
X
DP
WCH00503
94667A 1 Lifting plate
for removal and installation of water
separator
including:
4 screws M12x25
X = 305 mm
X
DP
