Maintenance9403−5/A1
Winterthur Gas & Diesel Ltd.
36/45
94663C
94663D
2
2
Lugs
X = 115 mm
Safety chains
X =1222 mm (SAC285)
(WLL 1000 kg)
X
016.822/08
X
94666 1 Wire rope sling Ø 14 mm
with 2 shackles
for removal and fitting of a crosshead pin
and a scavenge air cooler
X = 800 mm
(WLL 3000 kg at ( 0−45_)
012.316/04
X
Ø
94666I 2 Chains (double sling)
including: 4 Shackles
X = 554 mm
(WLL 1600 kg at ( 45−60_)
016.468/07
X
Tools for removal and installation of
scavenge air cooler SAC A44-SD, SAC 261-IL, SAC 265-IL
94661−IL 1 Support
including: 6 Screws M12x45
X = 1220 mm
X
DP
WCH00113
94663−IL 1 Lifting plate
including: 1 Shackle (WLL 6500 kg)
2 Shackles (WLL 4750 kg)
X = 779 mm
(A44: WLL 1400 kg at ( max. 135_)*
WCH00113
X
*
2020
Standard Tools
