Maintenance
9403−5/A1
Winterthur Gas & Diesel Ltd.
35/45
94657 4 Round sling (straight length
1250 mm, with TC at Driving End)
for removal and installation of auxiliary
blower (WLL 1000 kg)
94658 1 Support (with TC at Driving End)
for removal and installaton of auxiliary
blower
X = 1893 mm (WLL 800 kg)
X
WCH03036
Tools for removal and fitting of
scavenge air cooler SAC A46−SD
94661 1 Support
including: 1 Shackle (WLL 2000 kg)
4 Screws M12x35
X = 376 mm
Y = 255 mm
WCH00662
Y
X
94663A
94663B
1
1
Support LEFT
including: 1 Lug
1 Safety chain
6 Screws M16x40
X = 425 mm
Support RIGHT
including: 1 Lug
1 Safety chain
6 Screws M16x40
X = 425 mm
X
DP
94663B
94663A
94663D
94663C (DP)
X
2020
Standard Tools
