TRANSMISSION
M8540Narrow, M9540Narrow, WSM
N3-S3
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" at "NG. GENERAL" Section.)
9Y1210236TRS0003US0
Item N·m kgf·m lbf·ft
Brake pipe retaining nut 15.7 to 23.5 1.6 to 2.4 11.6 to 17.4
Engine and clutch housing mounting screw and nut
(M14, 7T)
124 to 147 12.6 to 15.0 91.2 to 108
Transmission case and clutch housing mounting screw
and nut (M10, 9T)
60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Transmission case and clutch housing mounting screw
and nut (M14, 9T)
166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
3-point hitch delivery pipe retaining nut 107.9 to 117.7 11.0 to 12.0 79.6 to 86.8
Cylinder hose retaining nut 34.3 to 48.1 3.5 to 4.9 25.3 to 35.4
3-point hitch hydraulic block mounting screw and nut 166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
Rear axle case mounting screw and nut 166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
PTO gear case mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Shuttle case mounting screw and nut 48.1 to 55.8 4.9 to 5.7 35.4 to 41.2
Shift cover mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Creep gear cover 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
PTO clutch holder mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
Differential bearing support mounting screw 48.1 to 55.8 4.9 to 5.7 35.4 to 41.2
Spiral bevel pinion shaft staking nut (Reference) 117.7 12.0 86.8
Spiral bevel gear mounting USB screw 142.2 to 161.8 14.5 to 16.5 104.9 to 119.3
PTO shaft staking nut 225.5 to 264.8 23.0 to 27.0 166.4 to 195.3
