BRAKES
M8540Narrow, M9540Narrow, WSM
N5-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" at "NG. GENERAL" section.)
9Y1210236BRS0002US0
Item N·m kgf·m lbf·ft
Brake rod turn backle lock nut 29.4 to 34.3 3.00 to 3.49 21.7 to 25.2
Breeder 6.4 to 6.9 0.66 to 0.70 4.8 to 5.0
Rear wheel mounting nut 260 to 304 26.5 to 31.0 192 to 224
Rear ROPS mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Rear axle case mounting screw and nut 166 to 196 17.0 to 20.0 123 to 144
Stabilizer bracket mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Stabilizer bracket mounting nut (M16, 7T) 197 to 225 20.0 to 23.0 145 to 166
