CLUTCH
M8540Narrow, M9540Narrow, WSM
N2-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" at "NG.GENERAL" section.)
9Y1210236CLS0002US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.8 to 224.2
Rear ROPS mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 191.8 to 224.2
Brake pipe retaining nut 16.0 to 24.0 1.6 to 2.5 11.8 to 17.7
Transmission case and clutch housing mounting screw
(M10, 9T)
60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Transmission case and clutch housing mounting screw
and nut (M14, 9T)
166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
PTO clutch holder mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
