wsm M8540NARROW - Pto Clutch Operation

CLUTCH
M8540Narrow, M9540Narrow, WSM
N2-M3
[2] PTO CLUTCH OPERATION
When the PTO switch (1) is set to the "B" position,
the PTO solenoid valve (3) is operated.
Then the oil flows to clutch pack through the PTO
solenoid valve (3). When the PTO switch is set to the "A"
position, the PTO solenoid valve (3) is not operated.
9Y1210236CLM0002US0
(1) PTO Switch
(2) Solenoid Valve Assembly
(3) PTO Solenoid Valve
A: Disengage
B: Engage
KiSC issued 07, 2013 A
