FRONT AXLE
M8540Narrow, M9540Narrow, WSM
N6-S1
1. SERVICING SPECIFICATIONS
9Y1210236FAS0001US0
Item Factory Specification Allowable Limit
Front Wheel Steering Angle 0.646 to 0.680 rad
37.0 to 39.0 °
–
Turning Angle Inspection Switch Operating Angle 0.53 to 0.59 rad
30 to 34 °
–
Spiral Bevel Pinion Shaft (Pinion Shaft
Only)
Turning Torque 1.43 to 1.56 N·m
0.145 to 0.16 kgf·m
1.05 to 1.15 lbf·ft
–
Front Bracket to Rear Bracket Bushing
• Rear Differential Case Boss
• Front Differential Case Boss
Alloy Thickness
O.D.
O.D.
0.57 mm
0.0224 in.
89.965 to 90.000 mm
3.5420 to 3.5433 in.
59.97 to 60.000 mm
2.3611 to 2.3622 in.
–
–
–
Front Wheel Case Bushing
• Bevel Gear Case
Alloy Thickness
O.D.
0.57 mm
0.0224 in.
54.97 to 55.00 mm
2.1642 to 2.1653 in.
–
–
To Next Page
