GENERAL
M8540Narrow, M9540Narrow, WSM
NG-30
[6] CHECK POINT OF EVERY 400 HOURS
Cleaning Water Separator
This job should not be done in the field, but in a clean place.
1. Close the fuel cock (1).
2. Unscrew the retainer ring (2) and remove the cup (3), and rinse
the inside with kerosene.
3. Take out the element (5) and dip it in the kerosene to rinse.
4. After cleaning, reassemble the water separator, keeping out
dust and dirt.
5. Bleed the fuel system. (Refer to "[14] OTHERS" in this section.)
9Y1210236GEG0038US0
(1) Fuel Cock
(2) Retaining Ring
(3) Cup
(4) O-ring
(5) Element
(6) Spring
(7) Red Float
(A) Close
[A] ROPS Model
[B] CABIN Model
