TRANSMISSION
M8540Narrow, M9540Narrow, WSM
N3-S5
(2) CABIN Model
Checking Function of Main Gear Shift
1. Check the function of the main gear shift.
• Neutral position to 1st gear position.
• Neutral position to 2nd gear position.
• Neutral position to 3rd gear position.
• Neutral position to 4th gear position.
• Neutral position to 5th gear position.
2. If shifting is not smooth, check the length of main shift rod (1).
The select cable (2) are fixed at the center of thread.
9Y1210236TRS0005US0
Length of select shift rod
"L"
Factory specification
655 mm
25.8 in.
(1) Main Shift Rod
(2) Select Cable
L: Select Shift Rod Length
