wsm M8540NARROW - 4 Lubricants, Fuel and Coolant; Rops Model

GENERAL
M8540Narrow, M9540Narrow, WSM
NG-10
4. LUBRICANTS, FUEL AND COOLANT
[1] ROPS MODEL
*
1
Refer to the "[4] TYPE OF ENGINE OIL" in this section.
*
2
KUBOTA original transmission hydraulic fluid.
9Y1210236GEG0004US0
No. Place Capacity Lubricants, fuel and coolant
1 Fuel tank
60 L
15.9 U.S.gals
13.2 Imp.gals
• No. 2-D diesel fuel
• No. 1-D diesel fuel if temperature
is below –10 °C (14 °F)
2
Coolant
9.0 L
9.5 U.S.qts
7.9 Imp.qts
Fresh clean water with anti-freeze
Recovery tank
1.0 L
1.1 U.S.qts
0.9 Imp.qts
3
Engine crankcase
(with filter)
10.7 L
11.3 U.S.qts
9.4 Imp.qts
Engine oil
API Service Classification*
1
CF,
or CI-4 [External EGR Type]
• Below 0 °C (32 °F)
SAE10W,
10W-30 or 15W-40
• 0 to 25 °C (32 to 77 °F)
SAE20, 10W-30 or 15W-40
• Above 25 °C (77 °F)
SAE30, 10W-30 or 15W-40
4 Transmission case
52 L
54.9 U.S.qts
46 Imp.qts
KUBOTA SUPER UDT fluid*
2
5
Front differential case
oil
5.0 L
5.3 U.S.qts
4.4 Imp.qts
KUBOTA UDT or KUBOTA SUPER
UDT fluid*2 or SAE80, SAE90 gear
oil
6
Front axle gear case oil
(one side)
3.0 L
3.2 U.S.qts
2.6 Imp.qts
Greasing
No. Place No. of greasing point Capacity Type of grease
7
Front axle gear case
support
2
Until grease overflows
Multipurpose grease
NLG1-2 or NLG1-1
(GC-LB) grease
Front axle support 2
Top link 2
Top link bracket 2
Lift rod 2
Hydraulic lift cylinder
pin
4
Battery terminal 2 Moderate amount
Multipurpose
type grease or
petroleum jelly
