GENERAL
M8540Narrow, M9540Narrow, WSM
NG-51
9Y1210236GEG0087US0
[3] WHEEL HUB
9Y1210236GEG0077US0
Tread (a) A B C D E F G
13.6R28 – –
1151 mm
(45.31 in.)
1264 mm
(49.76 in.)
1354 mm
(53.31 in.)
1467 mm
(57.76 in.)
–
14.9LR20
1112 mm
(43.78 in.)
1221 mm
(48.07 in.)
–
1096 mm
(43.15 in.)
1248 mm
(49.13 in.)
1357 mm
(54.43 in.)
–
230 / 95R32 –
1000 mm
(39.37 in.)
1212 mm
(47.72 in.)
1262 mm
(49.68 in.)
1350 mm
(53.15 in.)
1400 mm
(55.12 in.)
–
230 / 95R36 – –
1202 mm
(47.32 in.)
1256 mm
(49.45 in.)
1360 mm
(53.54 in.)
1414 mm
(55.67 in.)
–
320 / 85R24 –
985 mm
(38.8 in.)
1223 mm
(48.15 in.)
1332 mm
(52.44 in.)
1276 mm
(50.24 in.)
1385 mm
(54.53 in.)
–
320 / 85R28 – – –
1232 mm
(48.50 in.)
1286 mm
(50.63 in.)
1326 mm
(52.20 in.)
1380 mm
(54.33 in.)
340 / 85R28 – –
1151 mm
(45.31 in.)
1264 mm
(49.76 in.)
1354 mm
(53.31 in.)
1467 mm
(57.76 in.)
–
360 / 70R20
1112 mm
(43.78 in.)
1221 mm
(48.07 in.)
–
1096 mm
(43.15 in.)
1248 mm
(49.13 in.)
1357 mm
(54.43 in.)
–
380 / 70R24 –
985 mm
(38.8 in.)
1223 mm
(48.15 in.)
1332 mm
(52.44 in.)
1276 mm
(50.24 in.)
1385 mm
(54.53 in.)
–
380 / 70R
20
1
112 mm
(43.78 in.)
1221 mm
(48.07 in.)
–
1096 mm
(43.15 in.)
1248 mm
(49.13 in.)
1357 mm
(54.43 in.)
–
380 / 70R28 – –
1060 mm
(41.73 in.)
1154 mm
(45.53 in.)
1266 mm
(49.84 in.)
1348 mm
(53.07 in.)
–
420 / 65R24 – –
1156 mm
(45.51 in.)
1265 mm
(49.80 in.)
1343 mm
(52.87 in.)
1452 mm
(57.17 in.)
–
420 / 70R28 – – –
1264 mm
(49.76 in.)
1354 mm
(53.31 in.)
1467 mm
(57.76 in.)
–
440 / 65R24 –
1101 mm
(43.35 in.)
1107 mm
(43.58 in.)
1216 mm
(47.87 in.)
1392 mm
(54.80 in.)
1501 mm
(59.09 in.)
–
(1) Rear Wheel Disc (2) Rear Wheel Rim (a) Tread
Front wheel hub Rear wheel hub
Screw circle diameter (A) 203.2 mm (8 in.) 203.2 mm (8 in.)
Number of screws 8 8
Screws M16 × P1.5 M16 × P1.5
Hub pilot diameter (B) 152.4 mm (6 in.) 152.4 mm (6 in.)
