wsm M8540NARROW - 1 Servicing Specifications

CABIN
M8540Narrow, M9540Narrow, WSM
N10-S1
1. SERVICING SPECIFICATIONS
9Y1210236CAS0001US0
Item Factory Specification Allowable Limit
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
Pressure
(HI Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Setting Pressure
(HI Pressure Side)
Less than
approx. 0.196 MPa
2.0 kgf/cm
2
28.4 psi
More than
approx. 3.14 MPa
32 kgf/cm
2
455 psi
–
–
KiSC issued 07, 2013 A
