wsm M8540NARROW - Implement Capacity

GENERAL
M8540Narrow, M9540Narrow, WSM
NG-54
[1] IMPLEMENT CAPACITY
NOTE
• Implement size may very depending on soil operating conditions.
9Y1210236GEG0080US0
No. Implement Remarks
M8540Narrow, M9540Narrow Cabin
ROPS / CABIN
1 Trailer
Max. Load Capacity Refer to the next page
Max. Drawbar Load Refer to the next page
2Mower
Rotary-
Cutter
Max. Cutting Width 2130 mm (84 in.)
Max. Weight 540 kg (1200 lbs)
Flail
Mower
(Heavy)
Max. Cutting Width 3050 mm (120 in.)
Max. Weight 800 kg (1760 lbs)
Sickle
Bar
Max. Cutting Width 2130 mm (84 in.)
3 Sprayer
Max.
Tan k -
capacity
Mid 680 L (180 U.S.gals, 150 Imp.gals)
Rear
3-point
Hitch
680 L (180 U.S.gals, 150 Imp.gals)
Drawbar 4000 L (1030 U.S.gals, 880 Imp.gals)
4 Rotary Tiller
Max. Tilling Width 2130 mm (84 in.)
Max. Weight 800 kg (1760 lbs)
5 Bottom Plow
Max. Size
14 in. × 3
16 in. × 2
18 in. × 1
Max. Weight
(3-point Hitch Type)
450 kg (1000 lbs)
6
Disc-
harrow
3-point
Hitch
Type
Max. Size 18 in. × 24
Max. Harrowing
Width
2130 mm (84 in.)
Max. Weight 450 kg (1000 lbs)
Drawbar
Type
Max. Harrowing
Width
2750 mm (108 in.)
7 Disc Plow
Max. Size
24 in. × 3
26 in. × 2
Max. Weight 450 kg (1000 lbs)
8 Sub Soiler
Numbers of
Cultivating Tines
2
Cultivating Depth 400 mm (16 in.)
9 Cultivator
Max. Width 3660 mm (144 in.)
Number of Rows 4
Max. Weight 450 kg (1000 lbs)
KiSC issued 07, 2013 A
