HYDRAULIC SYSTEM
M8540Narrow, M9540Narrow, WSM
N8-S5
(Continued)
[Power Steering Pump Delivery]
Condition
• Engine speed
Approx. 2600 min
-1
(rpm)
• Rated pressure
18.1 MPa
185 kgf/cm
2
2631 psi
• Oil temperature
50 to 60 °C
122 to 140 °F
[Three Point Pump Delivery]
Condition
• Engine speed
Approx. 2600 min
-1
(rpm)
• Rated pressure
19.1 MPa
195 kgf/cm
2
2770 psi
• Oil temperature
50 to 60 °C
122 to 140 °F
9Y1210236HYS0003US0
Hydraulic pump delivery
at no pressure
Factory specification
Above
21.8 L/min
5.76 U.S.gals/min
4.80 Imp.gals/min
Hydraulic pump delivery
at rated pressure
Factory specification
21.3 L/min
5.63 U.S.gals/min
4.69 Imp.gals/min
Allowable limit
18.0 L/min
4.76 U.S.gals/min
3.96 Imp.gals/min
Hydraulic pump delivery
at no pressure
Factory specification
Above
63.0 L/min
16.64 U.S.gals/min
13.86 Imp.gals/min
Hydraulic pump delivery
at rated pressure
Factory specification
61.0 L/min
16.1 U.S.gals/min
13.4 Imp.gals/min
Allowable limit
51.5 L/min
13.6 U.S.gals/min
11.3 Imp.gals/min
