03/2003
4-141
8850/ 510DP
REP 14.1
Repairs and Adjustments
Replacement
1. (Figure 3): Lower the Printer Top Cover.
Figure 5 Lowering the Printer Top Cover
2. Close and secure the Rear Door.
3. Return the Printer to normal operation.
1
Raise the Top Cover
slightly with the left hand
2
Pull the latch forward with the right
hand
3
Gently lower the Top Cover
To Next Page
