03/2003
4-23
8850/ 510DP
REP 7.14
Repairs and Adjustments
5. (Figure 5): Remove the Pinch Rolls.
Figure 5 Removing the Pinch Rolls
Replacement
The replacement is the reverse of the removal. Ensure that the spring is applying pressure on
the shaft.
1
Remove the Shaft
from the frame
2
Remove the Rolls
