Xerox Phaser 4500 Service Manual

Error Messages and Codes 3-23
“Fuser Failure\Press i” Fuser Fails at warm-up
U4-4: Fuser Fail/ Power
Off
1 — Go to
page 3-28.
“Fuser Failure\Press i” Fuser Thermistor Failure
U4-5: Fuser Fail/ Power
Off
1 — Go to
page 3-28.
“Toner Is Low\ Press i” J5: Toner Low — — Go to “Toner
Sensor” on
page 23
“Fan Failure\ Power Off Now\
Press i”
U5: Fan Fail/ Power Off 0 — Go to
page 3-29.
“Install Or Reseat Print
Cartridge\ Press i”
J3: Missing Print Cartridge — — Go to
page 3-59.
“Replace Print Cartridge\
Press i”
———Go to
page 3-60.
“Close Top Cover\ Press i” Top Cover Open — — Go to
page 3-56.
“Close Rear Cover\ Press i” Rear Cover Open — — Go to
page 3-56.
“Jam At Tray N; Remove
Trays And Open Top Cover
To Clear\ Press i “
E2-01 Feed Jam
E2-02 Feed Jam
E2-03 Feed Jam
E2-04 Feed Jam
—1
2
3
4
Go to
page 3-32.
“Jam At Tray N; Remove
Trays And Open Top Cover
To Clear\ Press i “
E2-11 Feed Jam
E2-12 Feed Jam
E2-13 Feed Jam
E2-14 Feed Jam
—1
2
3
4
Go to
page 3-35.
“Jam At Top; Open Top
Cover To Clear\ Press i”
E3-1 Reg. Jam
E3-2 Reg. Jam
— 6 Go to
page 3-38.
“Jam At Exit; Open Rear
Cover To Clear\ Press i”
E4-2 Exit Jam — 5 Go to
page 3-41.
“Jam At Exit; Open Rear
Cover To Clear\ Press i”
E4-3 Exit Jam — 5 Go to
page 3-41.
“Jam At Exit; Open Top
Cover To Clear\ Press i”
E4-0 Exit Jam — 5 Go to
page 3-41.
“Jam At Duplex; Open
Duplex To Clear\ Press i “
E7-0 Duplex Jam — 7 Go to
page 3-49.
Error Message Summary
Front Panel Message Diagnostic Message
Engine
Errors
Jam
Errors
Procedure
to Use
