3-24 Phaser 4500 Service Manual
“Jam At Rear; Open Duplex
And Rear Cover To Clear\
Press i “
E7-1 Duplex Jam — 7 Go to
page 3-47.
“Jam At Duplex; Open
Duplex To Clear\ Press i “
E7-2 Duplex Jam — 7 Go to
page 3-47.
“Jam At Duplex; Open
Duplex To Clear\ Press i “
E7-3 Duplex Jam — 7 Go to
page 3-47.
“Jam At Rear; Open Rear
Cover To Clear\ Press i “
E6-1 Stacker jam — 8 Go to
page 3-43.
“Jam At Stacker; Open Rear
Stacker Cover To Clear\
Press i “
E6-2 Stacker Jam — 9 Go to
page 3-45.
“Paper Size Jam; Check
Paper Tray Guides And Open
Rear Cover To Clear\
Press i”
PSE-1 Paper Size Error — 10 Go to
page 3-54.
“Insert Tray 1\ Press i” Tray 1 Out — — Go to
page 3-65
“Insert Tray 2\ Press i” Tray 2 Out — — Go to
page 3-65
“Insert Tray 3\ Press i” Tray 3 Out — — Go to
page 3-66
“Insert Tray 4\ Press i” Tray 4 Out — — Go to
page 3-66
“Tray 2 Paper Is Low\ Press i” N/A — — Go to
page 3-62
“Tray 3 Paper Is Low\ Press i” N/A — — Go to
page 3-64
“Tray 4 Paper Is Low\ Press i” N/A — — Go to
page 3-64
“No Paper in Tray 1\ Press i” Tray 1 empty — — Go to
page 3-61.
“No Paper in Tray 2\ Press i” Tray 2 empty — — Go to
page 3-61.
“No Paper in Tray 3\ Press i” Tray 3 empty — — Go to
page 3-63.
Error Message Summary
Front Panel Message Diagnostic Message
Engine
Errors
Jam
Errors
Procedure
to Use
