Print-Quality Troubleshooting 5-27
5
Warning: Allow the Fuser Assembly
to cool before removing.
1. Open the Rear Cover and remove
the Fuser Assembly.
2. Rotate the Fuser Drive Gear
manually and inspect the Heat
Roller.
3. Open the Fuser Jam Access
Cover.
4. Rotate the Fuser Drive Fear
manually and inspect the
Pressure Roller.
Are the Heat Roller and the
Pressure Roller free of surface
defects and contamination?
Go to Electrical
Noise (page 4-41).
Replace the Fuser
Assembly (page 8-54).
Vertical Streaks Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
