Xerox Phaser 4500 Service Manual

5-46 Phaser 4500 Service Manual
4
The skewed image
occurs on prints fed from
Tray 2.
■ Check the Tray 2 Feed
Rollers. Clean or replace if
necessary.
■ Check the Tray 2 Retard Pad/
Retard Roller. Clean or replace
if necessary.
■ Check the Tray 2 Nudger
Roller. Clean or replace if
necessary.
■ Check the Tray 2 Transport
Rollers. Check for obstructions
or contamination. Clean as
necessary.
■ Check the feed chute
between Tray 2 and Tray 1.
Check for obstructions or
contamination. Clean as
necessary.
■ Check condition of paper tray.
Replace if necessary.
Go to step 5.
5
The skewed image
occurs on prints fed from
Tray 3.
■ Check the Tray 3 Feed
Rollers. Clean or replace if
necessary.
■ Check the Tray 3 Retard Pad/
Retard Roller. Clean or replace
if necessary.
■ Check the Tray 3 Nudger
Roller. Clean or replace if
necessary.
■ Check the Tray 3 Transport
Rollers. Check for obstructions
or contamination. Clean as
necessary.
■ Check the feed chute
between Tray 3 and Tray 2.
Check for obstructions or
contamination. Clean as
necessary.
■ Check condition of paper tray.
Replace if necessary.
■ Check the Tray 4
Feed Rollers. Clean or
replace if necessary.
■ Check the Tray 4
Retard Roller. Clean
or replace if
necessary.
■ Check the Nudger
Roller. Clean or
replace if necessary.
■ Check the Tray 4
Transport Rollers.
Check for obstructions
or contamination.
Clean as necessary.
■ Check the feed
chute between Tray 4
and Tray 3. Check for
obstructions or
contamination. Clean
as necessary.
Skewed Image Troubleshooting Procedure (Continued)
