Parts Lists 9-13
FRU Parts List 5.1 150-Sheet Paper Feeder
No. Name/Description Part Number
1 150 FEEDER ASSY (with 4-12, 14-23, 25-35, 37-44, 46-51) 604K16682
2 FDR1 AS SUB 150 A4 (with 4-10, 12, 14-20, 22, 25-28, 31-35, 40-42,
46-50)
3 CHUTE ASSY FDR 1 (Reference Only) (with 4-10,14-20,40-42)
4 SUPPORT NUDGER
5 HOLDER LEFT
6 ACTUATOR NO PAPER
7 GEAR IDLER NUDGER
8 HOLDER RIGHT
9 SHAFT NUDGER
10 GEAR NUDGER 059K25270
11 ROLL ASSY NUDGER (part of item 97)
12 ROLL REGI RUBBER
14 COVER ACTUATOR
15 ACTUATOR A (part of Registration Actuator)
16 SPRING REGI SNR B
17 ACTUATOR B (part of Registration Actuator)
18 SPRING REGI SNR A
19 CHUTE BTM ASSY
20 BEARING NUDGER
21 CLUTCH ASSY PH (J242) (Feed Clutch Assembly) 121K28511
22 BEARING REGI LEFT
23 CLUTCH REGI (J243) 121K28511
25 CHUTE REGI
26 VARISTER
27 EARTH PLATE BASE
28 EARTH PLATE MID
29 COVER SENSOR
30 SENSOR REGI (J241) 130E81970
31 SPRING REGI 809E41093
32 BEARING REGI RIGHT
33 GEAR REGI 807E01290
