9-14 Phaser 4500 Service Manual
34 ROLL REGI METAL
35 CHUTE EARTH REGI
37 HARNESS ASSY TRAY1 (J245-J240,J241,J242,J243,J244)
38 SENSOR NO PAPER (P240) 130E81970
39 COVER HARNESS R
40 CHUTE TOP ASSY
41 SHAFT FEED
42 CLUTCH ONEWAY NUDGER
43 CLUTCH ONEWAY FEED 005E16941
44 ROLL ASSY FEED (part of item 97)
45 SENSOR TONER ASSEMBLY (with 46-50) 130K63601
46 SENSOR TONER (J220)
47 HOLDER-D (part of item 46)
48 SPRING TONER (part of item 46)
49 SPRING (part of item 46)
50 HARNESS ASSY TONER 1 (J220-P221)
51 GEAR REGI METAL (WHITE)
97 Roller Kit (with 11 or 44, Qty. 3) 604K11192
98 KIT CHUTE REGI (with 25-28)
99 KIT CHUTE BTM (with 14-19)
FRU Parts List 5.1 150-Sheet Paper Feeder (Continued)
No. Name/Description Part Number
To Next Page
