9-38 Phaser 4500 Service Manual
Parts List 21.1 Duplex Unit
No. Name/Description Part Number
1 HSG UPPER ASSY (with2-4) 802K46801
2 HSG UPPER DUP
3 SPRING PINCH 809E37140
4 ROLL PINCH 059E97500
6 HSG LOWER DUP
7 HARNESS ASSY DUP (J50-JD2750)
8 EARTH ASSY PLATE
9 COVER HARNESS
10 SCREW THUMB
11 SCREW HINGE
12 COVER TOP
13 LEVER LATCH RIGHT
14 SHAFT LATCH
15 LEVER LATCH LEFT
16 SPRING LATCH
17 ROLLER DUP 059E97811
18 COVER HSG DUP
19 BEARING DUP 013E22671
20 GEAR ROLLER
21 GEAR IDLE29
22 GEAR IDLE47
23 GEAR IDLE77
24 GEAR IDLE57/37
25 COVER LEFT
26 BRACKET MOTOR
27 SWITCH DUPLEX (P520) 110E10200
28 HARNESS ASSY DUP EARTH (J56-JD560)
29 MOTOR DUPLEX (J51) 127E83201
30 CLAMP EDGE
31 HARNESS ASSY DUP COVER (J52-J520)
32 PWBA DUPLEX 160K86756
33 FAN DUPLEX (J54) 127E83210
